Insulation Fasteners For Welding
Insulation fasteners are special pins used to install insulation on the inside or outside of furnace shells, secure insulation inside steel buildings, attached to cloth seals used to secure and protect sensitive equipment from heat. Insulation fasteners for welding come in many different types such as cup head weld pins, double-pointed pins, self-locking washers and speed clips, lasing anchors, adhesive and non-adhesive backed pins. Insulation fasteners are available in many different grades of steel ranging from mild/carbon to stainless steel depending on the application.
Low Carbon Steel | Stainless Steel | Aluminum. Copper plating standard on Mild Steel Pins.
|
PINS |
||
|
D |
C |
LENGTH |
|
12 GA. .106 |
.170 |
as required |
|
10 GA. .135 |
.187 |
as required |
Double pointed studs used to secure all types of insulating materials. All orders for studs include required ferrules.
|
STUD SPECIFICATION |
FERRULE SPECIFICATION |
||||||
|
D |
Min. L |
NO. |
B |
D |
M |
F |
|
|
10 GA. |
.135 |
3/4 |
FB135 |
.305 |
.375 |
.390 |
.234 |
|
LENGTH |
STD. PACK |
WGT/CTN |
|
1 |
1,000 |
31 lbs |
|
1 5/8 |
1,000 |
32 lbs |
|
2 |
1,000 |
34 lbs |
|
2 1/2 |
1,000 |
35 lbs |
|
3 1/2 |
500 |
19 lbs |
|
4 1/2 |
500 |
20 lbs |
|
5 1/2 |
500 |
21 lbs |
|
6 1/2 |
500 |
23 lbs |
|
8 |
250 |
13 lbs |
General Purpose Adhesive
|
Number per Carton |
Container |
Approx. Weight per Carton |
|
12 |
QUART |
32 lbs |
|
4 |
GALLON |
38 lbs |
Come complete with a special pressure-sensitive adhesive pre-applied to the base plate of the hanger and protected with release paper.
|
LENGTH |
STD. PACK |
WGT/CTN |
|
1 |
1,000 |
44 lbs |
|
1 5/8 |
1,000 |
46 lbs |
|
2 |
1,000 |
47 lbs |
|
2 1/2 |
1,000 |
49 lbs |
|
3 1/2 |
500 |
25 lbs |
|
4 1/2 |
500 |
26 lbs |
|
5 1/2 |
500 |
27 lbs |
|
6 1/2 |
500 |
28 lbs |
|
8 |
250 |
17 lbs |
Available with paper insulation washers which are beveled to prevent cutting of insulation material.
|
STANDARD SPECIFICATIONS |
|||||
|
TYPE |
D |
BD |
H |
Min. L |
Max. L |
|
CL10 |
.135 |
.375 |
1.500 |
.375 |
no max |
|
CL12 |
.105 |
.375 |
1.500 |
.375 |
no max |
|
CL12 |
.105 |
.500 |
1.187 |
.375 |
8.00 |
|
SELF LOCKING WASHERS (SPEED CLIPS) SPECIFICATIONS |
|||||
|
Size of Diameter |
2 1/2" x 2 1/2" |
1 1/2" x 1 1/2" |
1" x 1 1/4" |
1 3/4" |
1 1/2" |
|
Thickness |
.016 |
.016 |
.016 |
.016 |
.016 |
|
Material |
Mild Steel |
Mild Steel |
Mild Steel |
Mild Steel |
Mild Steel |
|
Plating |
Galvanized |
Galvanized |
Galvanized |
Galvanized |
Galvanized |
|
Edge |
Beveled |
Beveled |
Beveled |
Flat |
Beveled |
|
Other Materials Available |
Alum., S.S. |
Alum., S.S. |
Alum., S.S. |
Alum., S.S. |
Alum., S.S. |
|
SELF LOCKING WASHERS - 12 & 10 GAUGE |
||
|
Wt/Ctn Steel/Aluminum |
Std/Ctn |
Size/Diameter |
|
28 |
1000 pcs |
2 1/2 x 2 1/2 sq. |
|
28 |
1000 pcs |
2 1/2 x 2 1/2 sq. |
|
10 |
1000 pcs |
1 1/2 x 1 1/2 sq. |
|
10 |
1000 pcs |
1 1/2 x 1 1/2 sq. |
|
6 |
1000 pcs |
1 x 1 1/4 sq. |
|
6 |
1000 pcs |
1 x 1 1/4 sq. |
|
12 |
1000 pcs |
1 3/4 Dia. Rd. |
|
12 |
1000 pcs |
1 3/4 Dia. Rd. |
|
8 |
1000 pcs |
1 1/2 Dia. Rd. |
|
8 |
1000 pcs |
1 1/2 Dia. Rd. |
Lacing Anchor | 1 Hole Lacing Hook | 2 Hole Lacing Washer | Lacing Ring | Capped Self-Locking Washer
